As a dedicated China-based FRP pipe manufacturer and direct exporter, we combine over 15 years of filament-winding expertise with stringent ISO 9001:2025 quality management to deliver corrosion-resistant piping solutions tailored for aggressive environments—from high-salinity seawater intake in desalination facilities to acidic/alkaline media conveyance in petrochemical plants. Our factory-direct model eliminates intermediary markups, while our in-house R&D team supports custom diameters (up to 4 meters), pressure ratings, and joint systems (flanged, coupler, or butt-wrap) to meet project-specific specifications. With validated shipping partnerships to North America, Europe, and the Middle East, we ensure on-time delivery and full traceability from raw material batching to hydrostatic testing, empowering your infrastructure with lifecycle cost savings and operational safety.
Брошюра о продукте Hebei Fortis Technology Co., Ltd
Product Advantages
1. Unmatched Corrosion Resistance for Harsh Chemical Environments
Unlike carbon steel or cast iron, our FRP pipes are inherently inert to a wide spectrum of corrosive agents—including sulfuric acid, hydrochloric acid, alkaline slurries, and saltwater. The thermosetting resin matrix (available in orthophthalic, isophthalic, vinyl ester, or epoxy formulations) acts as a permanent barrier against electrochemical and microbiologically induced corrosion (MIC). This eliminates the need for expensive internal linings, cathodic protection, or frequent recoating, making our pipes the preferred choice for chemical dosing lines, effluent treatment, and coastal seawater intake systems where metal alloys would fail within months.
2. Sustainable Manufacturing and Cost-Effective Export Logistics
As a factory-direct exporter, we practice lean manufacturing with low-VOC (volatile organic compound) resin systems and recyclable glass fiber waste, aligning with global green procurement standards. Our vertical integration—from raw material resin and fiber sourcing to in-house fitting production—gives us full cost control, allowing us to offer competitive FOB, CIF, or CFR pricing without compromising quality. Combined with our established container-loading protocols (20' and 40' flat racks, open-top, or standard boxes) and experienced documentation team for customs clearance, we ensure that your order reaches site safely, promptly, and within budget—backed by full mill test reports (MTR) and third-party inspection acceptance (SGS/BV/TÜV optional).
3. Full Customization in Diameter, Joint System, and Resin Formulation
We are not limited to standard off-the-shelf sizes. Our factory offers flexible mandrel tooling to produce pipes from DN25 (1 inch) up to DN4000 (4 meters) in diameter, with pressure ratings, wall thicknesses, and lay-up sequences tailored to your hydraulic and structural specifications. For jointing, you can choose from adhesive-bonded bell-and-spigot joints, mechanical couplers, flanged connections, or field-applied butt-and-wrap joints—each designed for rapid, leak-tight assembly. Additionally, we can incorporate antistatic or flame-retardant additives, UV-resistant topcoats, or abrasion-resistant inner liners for slurry transport, ensuring that every pipe is a precise fit for your unique operational profile.
4. Proven Long-Term Service Life with Minimal Maintenance Intervention
Independent accelerated aging tests and field data from our installed base (spanning over two decades) confirm an operational lifespan of 50+ years for our FRP pipelines under normal service conditions. Because the composite material does not rust, rot, or suffer from stress corrosion cracking in chloride-rich media, maintenance activities are reduced to routine visual inspections rather than scheduled shutdowns for internal cleaning, chemical flushing, or weld-point patching. This reliability directly translates to lower total cost of ownership (TCO)—a metric increasingly valued by plant owners and infrastructure asset managers seeking predictable O&M (operations and maintenance) budgets.
Parameter Specifications
|
Product |
FRP pipe |
||||
|
|
|||||
|
Model |
Inner.dia(mm) |
Length(mm) |
Channel Thickness(mm) |
||
|
P=0.6Mpa |
P=1.0Mpa |
P=1.6Mpa |
|||
|
FT-Pp10 |
10 |
1800 |
4.6 |
4.6 |
4.6 |
|
FT-Pp15 |
15 |
||||
|
FT-Pp20 |
20 |
||||
|
FT-Pp25 |
25 |
||||
|
FT-Pp32 |
32 |
||||
|
FT-Pp40 |
40 |
||||
|
FT-Pp50 |
50 |
6000 |
|||
|
FT-Pp65 |
65 |
||||
|
FT-Pp80 |
80 |
||||
|
FT-Pp100 |
100 |
5.9 |
|||
|
FT-Pp125 |
125 |
||||
|
FT-Pp150 |
150 |
5.9 |
|||
|
FT-Pp200 |
200 |
5.9 |
7.2 |
||
|
FT-Pp250 |
250 |
12000 |
8.5 |
||
|
FT-Pp300 |
300 |
7.2 |
9.8 |
||
|
FT-Pp350 |
350 |
8.5 |
11.1 |
||
|
FT-Pp400 |
400 |
12.4 |
|||
|
FT-Pp450 |
450 |
7.2 |
9.8 |
13.7 |
|
|
FT-Pp500 |
500 |
||||
|
FT-Pp600 |
600 |
8.5 |
12.4 |
15.0 |
|
|
FT-Pp700 |
700 |
9.8 |
13.7 |
20.2 |
|
|
FT-Pp800 |
800 |
15.0 |
22.8 |
||
|
FT-Pp900 |
900 |
11.1 |
16.3 |
25.4 |
|
|
FT-Pp1000 |
1000 |
12.4 |
17.3 |
28.0 |
|
|
FT-Pp1200 |
1200 |
13.7 |
|
|
|
|
FT-Pp1400 |
1400 |
16.3 |
|
|
|
|
FT-Pp1500 |
1500 |
|
|
||
|
FT-Pp1600 |
1600 |
17.6 |
|
|
|
|
FT-Pp1800 |
1800 |
18.9 |
|
|
|
|
FT-Pp2100 |
2100 |
22.8 |
|
|
|
|
FT-Pp2400 |
2400 |
25.4 |
|
|
|
|
FT-Pp2600 |
2600 |
26.7 |
|
|
|
|
FT-Pp3000 |
3000 |
30.6 |
|
|
|
|
FT-Pp3300 |
3300 |
33.2 |
|
|
|
|
FT-Pp3600 |
3600 |
35.8 |
|
|
|
|
FT-Pp4000 |
4000 |
39.7 |
|
|
|
